Preformed Rods Dead End Guy Grips Tensile Clamp

Description

ADSS optical cable tension clamps are mainly used to connect ADSS optical cables to tension towers, corner towers and terminal towers. According to the span or the tensile strength of the optical cable, ADSS optical cable tension clamps are divided into three types: small span tension clamps, medium span tension clamps and large span tension clamps.
Small span tensile clamp for ADSS optical cable
The material of the small-span ADSS optical cable tension clamp is aluminum-clad wire or galvanized steel wire. It is mainly used for tension-resistant towers, corner towers, and intermediate connections where the tensile strength (RTS) of the optical cable does not exceed 15kN and the span does not exceed 100 meters. Optical cable connection of towers and terminal towers. ADSS medium/long span tension-resistant clamps for medium-span and long-span ADSS optical cables. Pre-twisted tension-resistant clamps for optical cables include inner and outer double layers of pre-twisted wires. The material is aluminum-clad steel wire or galvanized steel wire. The main It is used on optical cable lines such as tension towers, corner towers and terminal towers with an optical cable tensile strength (RTS) greater than 15kN and a span of 200 meters or more. Medium-span tension-resistant cable clamps are generally used for lines with a span of 200 meters to 400 meters, and large-span tension-resistant cable clamps are used for lines with a span of more than 400 meters.
